Our customer SXS PET extruded sheet can be cut and formed into a range of packaging products, including thermoform blisters, clamshells, trays, and a variety of packaging solutions. The exceptional clarity, impact performance and formability of our SXS PET extrusion make it best suited for packaging, thermoforming, as well as laminating applications. Available in AB and BAB extrusion process. Our dedicated engineering and design team can assist with your custom project needs. See link below for profile width and dimensions.
Side-By-Side PET Plastic Extrusion
Specifications:
- General Capabilities
J.I.T.
Contract
O.E.M.
- Industry Focus
Aerospace
Automotive
Consumer Packaging
Industrial Packaging
Food Packaging
Construction
Electrical
Medical
Transportation
- Resistance Characteristics
Acid
Strong Oxidizer
Alkalis
Hydrocarbon Solvent
Alcohol
Fat
Grease
Oil
- Colors/Styles
Clear
Custom Colors
- Coating
Anti-Static
Anti-Fog
- Industry Standards
AIB
ANSI
ASME
ASTM
FDA Certified
GMP
ISO
Kosher Certified
Mil-Spec
- Applications
Thermoforming
Braze Fabrication
- Extrusion Product
Roll Stock
- Extrusion Product Form
Profiles
Rods
Shapes
Sheet
- Extrusion Features
Flexible
Food Grade
High Temperature
Thin Gage
High Impact
Multi Color
- Additional Services Provided
Matte Finish
Online Gaging
Topical Coating
Sheet Finish
- Translucent
- Opaque
- Transparent
- Gauge
Min: 0.015 in (0.381 mm)
Max: 0.040 in (1.016 mm)
- Width
Min: 15 in (381 mm)
Max: 54 in (1371 mm)
- Core Size
3 in
6 in
- Roll O.D.
Min: 29 in (736.6 mm)
Max: 40 in (1016 mm)
- Specific Gravity
1.335
- Shrinkage
2.0% to 5.0%
- Yield
20,810 in2/lb/Mil of thickness
- Tensile Strength at Yield
Min: 8,000 PSI
Max: 9,000 PSI
- Flexural Modulus
Min: 325,000 PSI
Max: 370,000 PSI
- Intrinsic Viscosity
>=0.74
- Light Transmission
>=90%
- Haze
>=2%
- Clarity
>=99%
- Temperature Range
Min: 0° F (-18° C)
Max: 150° F (66° C)
- Gauge Tolerance (+/-)
5%
